Charnwood W619 Sawbench

£649.00

SKU: Charnwood W619 Categories: , ,

Charnwood W619 Sawbench

FREE Shipping to Mainland UK

Cast Iron Table Saw with an 8″ diameter blade.

Now available with an upgraded quick action precision rip fence.

  • Quiet Induction Motor

  • Cast Iron Precision Ground Table

  • Extension Tables as Standard Equipment

  • Sliding Carriage as Standard Equipment

  • Separate Hand wheels for Blade Adjustment

  • Quick Action Precision Rip Fence

  • 100mm Dust Extraction Outlet

  • Solid Floor stand Base Included

  • Optional Wheel Kit Available

W619 Table saw is a compact, high quality table saw with a quiet induction motor. The main table is precision ground cast iron, and has 2 fabricated side extension tables to give impressive cutting capacities, perfect for the smaller workshop. The induction motor turns the blade via a drive belt which reduces noise and increases accuracy. Blade height and blade angle are controlled using 2 separate hand wheels. The sliding carriage, included as standard, is a joy to use with a cast iron bed travelling on 4 bearing guides. Any angle can be set on the long support fence. A screw clamp holds the work secure and a flip over length stop is fitted for repeat cuts.

Supplied with 18 tooth TCT sawblade, sliding carriage, extension tables, floor stand, adjustable feet, push stick, 2.0m power cable and UK 3 pin plug.

There are 3 ways to configure the table saw:
The sliding carriage can be fitted on either side of the blade so that you can work on the left or right.
If you are not using the sliding carriage, you can fit one extension table on either side of the blade.

For compact storage the extension tables and sliding carriage can be quickly removed, (2 minutes). They reassemble without any further setting up required.

Specification

Main Table Size

530mm x 1000mm

Maximum Ripping Width Using Fence

730mm

Crosscut Table Size

400mm x 180mm

Maximum Crosscutting Width

600mm (700mm Using Reverse Table)

Blade Tilt

90 – 45 degrees

Cutting Depth at 90 degrees

60mm

Cutting Depth at 45 degrees

47mm

Blade Diameter

200mm

Blade Bore

30mm

Work Table Height

860mm

Mitre Guide T-Slot Width

15/19mm

Mitre Guide T-Slot Depth

7mm

Motor (induction)

1100w (1.5hp) / 240v

No-Load Blade Speed

4700 rpm

Minimum Blade Width (Kerf)

2.6mm

Dimensions (WxDxH)

1460 x 1010 x 1030mm

Weight

90Kg

Rating

Light Trade

Warranty

1 Year

 It is highly recommended that a dust extractor is used at all times with this saw to prevent the harmful build up of dust and chips. The hose kit supplied collects dust from the sawguard and takes it to the single 100mm diameter hose connection point at the back of the machine.

Please note: It is not possible to use a stacked dado set with this saw.
