Jet JB0S-5 Oscillating Spindle Sander


A very versatile sander with oscillating bobbin and fully tilting table ideal for all manner of finishing tasks in the workshop. The oscillating motion of the bobbin prevents burning of the work as well as spreading the wear along the length of the abrasive. The cast iron table can be tilted up to 45° to allow for sanding of angled surfaces. There is a 50mm dust outlet provided at the rear of the machine and the use of a fine dust extractor is strongly recommended. The JBOS-5 sander is best suited to workshop use and has fitted as standard an exceptionally efficient extraction hood for dust free sanding when used with a suitable extractor. Also available as an additional accessory is a 76mm diameter bobbin, which will require an accompanying table insert.


Jet JB0S-5 Oscillating Spindle Sander


JET JBOS-5 Benchtop Oscillating Spindle Sander


25mm oscillating action reduces friction heat to protect wood and prolong sleeve life

Main spindle support runs on precision ball bearings and is oscillated by a heavy-duty worm and gear mechanism for consistent performance

Oscillating gears run in a closed lubrication box for a long service life

Powerful 0.7kW induction motor easily handles the toughest sanding projects

Large grey cast iron worktable for precise grinding of large workpieces, tiltable 45°


Motor (V/kW): 230/0.7

Spindle speeds: 1,450 rpm

Spindle diameter (diameter- mm): 6/12/16/38/50

Max. sanding height: 100mm

Table size: 370mm x 370mm

Table tilt: 0° – 45° down

Sanding spindle height: 150mm

Oscillations/Minute: 30

Osciallation stroke: 25mm

Dust port (diameter- mm): 100

Dimensions: 440mm x 430mm x 530mm

Weight: 35kg
