Record Power Victory 100 Special Edition Chuck Package – Direct Thread M33 x 3.5mm
62077
Professional Geared Scroll Chuck with Added Value
Experience exceptional work holding with the Victory Special Edition – an innovative professional chuck system designed for creative turners who demand precision, flexibility, and premium features in one box.
This exclusive bundle starts with the Victory Chuck – our flagship geared scroll chuck featuring:
Precision engineered 100 mm body
4-jaw geared mechanism for easy, secure clamping
VersaLock Included
Supplied with the 100 mm VersaLock-compatible modular base jaws, making it the perfect platform to experience the full range of VersaLock capabilities.
Safety Band Included
Gives protection from the edges of jaw slides and provides extra grip when changing jaws.
Torx Fixings
The Victory chuck is supplied with Torx fixings as standard, allowing the jaws to be held more securely than with standard fixing methods, increasing safety and performance.
Sealed Backing Plate with Full Indexing
The Victory features a strong backing plate to protect the gear mechanism from dust. It also features 72-point indexing around the full circumference.
Heavy-Duty Jaw Slides
Some of the widest available to provide a strong and stable base for the jaws.
Precision-Engineered Gears
Super Geared True-Lock™ technology ensures high levels of grip, providing smooth and accurate operation.
Jaw Fixing System
The Victory chuck is fitted with the patented 62690 VersaLock 50 mm Dovetail Modular Jaws and is also compatible with the full range of SC series jaws.
Deep Wood Screw
The Victory chuck is supplied with a useful deep wood screw. Ideal for mounting bowl blanks, this screw is held in the jaws of the chuck, giving exceptional holding power. This means a separate woodscrew chuck need not be used and the chuck can stay on the lathe, saving time and effort.
Supplied as standard with:
Victory Professional Geared Scroll Chuck
62686 VersaLock V100 100 mm Base Jaw
Deep wood screw
Ball-end hex key
Torx keys
Chuck fastenings kit
62825 Universal Wrench
Cleaning cloth “
The Special Edition Includes Even More Added Value:
Included in the box
62686 VersaLock V100 100 mm Base Jaw
The VersaLock V100 Base Jaw is a fully functional 100 mm dovetail jaw that also forms the foundation of the VersaLock insert system.
Designed for medium to larger projects, it allows turners to rapidly switch between specialised insert jaws without removing the base jaw from the chuck – reducing setup time while maintaining accuracy and holding security.
Expansion: 96 – 116 mm
Contraction spigot: 78 – 97 mm
Contraction square: 56 – 76 mm
62680 VersaLock V100 80 mm Adaptive Insert Jaw
Designed for greater holding confidence, the VersaLock Adaptive Jaw Insert delivers improved grip and tolerance across regular and imperfect workpieces alike. Its shaped internal profile maintains security beyond ideal design diameter – giving turners a more forgiving, more reliable hold within the patented VersaLock system.
Expansion: 81 – 101 mm
Contraction spigot: 51 – 70 mm
Contraction square: 38 – 59 mm
62691 VersaLock V100 50 mm Access Insert Jaw
The VersaLock Access Jaw Insert provides secure holding for small to medium bowls, platters and hollow forms while maintaining valuable tool access behind the workpiece for finishing cuts. A 50 mm expansion dovetail offers stable grip, while the internal hawk-beak profile provides strong contraction on small to medium tenons.
Expansion: 48 – 68 mm
Contraction spigot: 26 – 45 mm
Contraction square: 18 – 32 mm
62695 VersaLock V100 75 mm Precision Dovetail Insert Jaw
The VersaLock 75mm Dovetail Insert Jaw provides traditional, full-surface dovetail engagement for secure and predictable holding in both expansion and contraction.
Designed to pair perfectly with the 103616 Record Power Dovetail Tool, it delivers accurate, repeatable grip in the popular 75 mm size.
Expansion: 73 – 96 mm
Contraction spigot: 54 – 72 mm
Contraction square: 38 – 51 mm
Whatever you’re turning, the Victory Special Edition gives you the versatility to tackle more projects – with greater speed, control, and confidence.
Available as:
M33 x 3.5
M33 x 3.5 ASR
1-1/4″ x 8 TPI
